A Fresh Spin on Wind Turbines

A Fresh Spin on Wind Turbines
March 16, 2021 Waqar Qureshi

Background

When someone says wind turbine, something like the turbine in the image below would come to mind for most of us. Note that the heading says ‘Horizontal-axis wind turbine’, i.e. the rotational axis is aligned horizontally. These are the oldest and most common design of wind turbines used globally.

vertical axis wind turbines

Apart from some unconventional designs that are largely still in the conceptual or development phase, vertical-axis wind turbines are the other main design used globally. Although you are less likely to have seen one of these than a horizontal-axis turbine, they are not as new a technology as you might think. They are generally less capable of producing power and therefore do not tend to be used for large-scale wind farms. However, they offer some advantages, one of the most significant being that they do not need to be pointed into the wind to work effectively. This makes them particularly useful in areas where the wind direction may vary considerably or be difficult to predict. Other advantages include the greater ease and lower carbon cost of installation and maintenance.[2]

Mini Wind Turbines

Last year a Kent-based company called Alpha 311 showcased a new innovative design of vertical-axis wind turbine. They have a unique combination of size, material and weight, allowing them to turn very easily compared to larger turbines.

The potential applications for these turbines are very extensive. One is to tap into the vast amounts of energy produced by moving road vehicles by installing these turbines along busy roads and using the passing of cars to rotate the turbine and generate energy. With road traffic generally on the up, this is certainly an exciting idea. The company suggest housing these turbines onto existing lighting columns and initially powering the lights.[3] Eventually, they could be prevalent enough to help the UK meet its 2050 carbon neutral targets. They have been in talks with UK and US authorities to test the technology on roads.

vertical axis wind turbines

Figure 2: Wind turbine structure.[3] Image Accreditation: Alpha 311.vertical axis wind turbinesFigure 3: Wind turbine schematic.[3] Image Accreditation: Alpha 311.

Powering the O2

Very recently, Alpha 311 had a big breakthrough as AEG announced that they will be installing 10 of their turbines on the O2 Arena as they try to make their entertainment venues more environmentally sustainable.[4] They are the first to trial this technology globally. The turbines being installed measure 68cm, are made of lightweight recycled plastic and weigh around 4kg.[4] Alpha 311 estimate that these 10 turbines could produce up to around 87,600 kWhs of electricity per year, the equivalent of the power consumption of 23 British homes.[4] The O2 consumes quite a bit more than this, but this is just a trial and what they believe is a step in the right direction.

vertical axis wind turbines

Figure 4: An artist’s impression of the new turbine.[5]
Image Accreditation: Alpha 311.

Conclusion

These mini wind turbines have great potential, and Alpha 311 claim to be able to build larger models that could generate as much electricity as 20 square metres of solar panels.[4] In the future, we may see these along the motorway as we drive or even along railway tracks. Looking at the bigger picture, this seems a fitting way to partly offset the emissions produced by these modes of transport (or at least using the increased road traffic for something positive). AEG plan to install more of them across its venues in the UK.[5] Considering that they are one of the world’s largest sporting and music entertainment groups, this is a big feat for Alpha 311. If this trial goes well, we may see more of these types of wind turbines in future.

About Pager Power

Pager Power has expertise in helping wind developers assess the impacts of both offshore and onshore wind projects upon aviation and telecommunications as well as engaging with stakeholders. For more information about what we do, please get in touch.

References

[1]EIA, “Wind explained,” EIA, 4 December 2020. [Online]. Available: https://www.eia.gov/energyexplained/wind/types-of-wind-turbines.php. [Accessed 15 March 2021].
[2]Wikipedia, “Vertical Axis Wind Turbine,” Wikipedia, 14 March 2021. [Online]. Available: https://en.wikipedia.org/wiki/Vertical_axis_wind_turbine. [Accessed 15 March 2021].
[3]A. Malewar, “New wind turbine harvests the energy from passing traffic,” InceptiveMind, 17 October 2020. [Online]. Available: https://www.inceptivemind.com/alpha-311-wind-turbine-harvests-energy-passing-traffic/15774/. [Accessed 15 March 2021]. Image Accreditation Alpha 311.
[4]O. Haill, “New breed of mini wind turbines installed at O2 arena,” Proactive Investors Limited, 12 March 2021. [Online]. Available: https://www.proactiveinvestors.co.uk/companies/news/943743/new-breed-of-mini-wind-turbines-installed-at-o2-arena-943743.html. [Accessed 15 March 2021].
[5]S. Williams, “Whitstable firm Alpha 311’s wind turbines to be installed at 02,” KentOnline, 13 March 2021. [Online]. Available: https://www.kentonline.co.uk/whitstable/news/kent-firms-innovative-turbines-to-be-installed-at-o2-243928/. [Accessed 15 March 2021]. Image Accreditation Alpha 311.
